TMS-9 Premium

---

MUSIC SERVER (MS)	Raspberry Pi 4
Software	Volumio
USB	2 x USB 2.0 (Total max 100mA)
	2 x USB 3.0 (USB, HDD, SSD . . . Total max 500mA)
LAN	Gigabit
Decoder	Audio Decoder by 32bit R-2R Module
Display	Oled Display
Analog Inputs	1 RCA ;  2 XLR ; 1 MS
	1 MM / MC RIAA Phono
Analog Outputs (Rear)	1 Stereo Pair of RCA
	1 Stereo Pair of XLR
Headphone Outputs (front)	1/4″ (6.3mm) stereo
	4-pin XLR stereo
	Dual 3-pin XLR (left and right channel)
Line Preamp
Tubes	2 x 6SN7    2 x 300B
Coupling	Single Ended Transformer
Gain	Max +10dB / +30dB (Normal / +20dB switch)
HUM Noise	< 0.1 mV
Phono RIAA	MM : +40dB  / 47k
	MC  : +60dB
Frequency response	10Hz – 30kHz (+/-0.4dB)
Power Requirements	230V (possible to set 100 /110/115/240v/50-60Hz by different markets)
Power Consumption	90W
Dimensions (W x D x H)	45 x 50 x 33 (cm)
Weight	48kgs
Remote control	Included



---



introduce about the superiority of ThivanLabs’s Point-to-point method and engineering strengths in vacuum tube equipment
(click on to read and discover more)

* MUSIC SERVER

The main function of the TMS-9 Premium is using as a High End Music Server.

– Audio Decoder by 32bit R-2R Module

– Streaming music

– Playing music directly from USB, HDD, SSD

– Managing and choosing music on smartphone, tablets, iphone/ipad, computer (PC/Laptop) by apps

– Oled Display Screen

– TMS-9 supports popular PCM and DSD formats



* 300B Class A Single Ended Preamplifier with MM Phono (or option MM/MC phono)

– 5 Input : 1 x RCA ; 2 x XLR ; 1 x MS ; 1 x MM/MC Phono

– 2 Output : 1 x RCA or 1 x True XLR

– Max gain : +10dB / +30dB (with +20dB switchable)

– Output with Transformers

– LINEAR POWER SUPPLY with Huge chokes and PIO capacitors

– MM Phono : gain +40dB / 47k

– MC Phono : gain +60dB

– Volume Control including a remote



* High end 300B Single-ended Headphone Amplifier

– Optimal to push 150 – 1200 Ohms headphonesHeadphone Outputs:

– 1/4″ (6.3mm) stereo headphone

– 4-pin XLR stereo headphone

– Dual 3-pin XLR (left and right channel) headphone





---





---





---





---





---





---





---





---





---





---



---
