Inputs | 2 RCA (MM RIAA Phono) |
1 RCA (MC RIAA Phono) | |
Outputs | 1 RCA ; 1 XLR |
Vacuum tube complement | 2 x 12AX7 ; 1 x 12AU7 |
1 x 6SN7 Single Ended with Special Output Transformers | |
Frequency response | 20Hz – 20kHz (+/-3dB) |
HUM Noise | < 0.2 mV |
Gain | MM 46dB ; MC 66dB |
Max Voltage Output | > 20Vp-p |
Input Impedance | MM 47kOhm |
MC Load impedance : 22 , 47, 100, 220, 470 ohm | |
Power Requirements | 230V (possible to set 100 / 110 / 117 / 240V / 50-60Hz by different markets) |
Power Consumption | 30W |
Dimensions (W x D x H) | 45 x 40 x 12.5 (cm) |
Weight (kg) | 18kgs |
Display | No |
Remote control | Included |
